| Service | : | Indoor |
| Application | : | Suitable for Metering & Relaying application in AC Power Systems. |
| System Voltage | : | Up to 1.1kV |
| VT Ratio | : | 110V/110V, 110V/RT3//110V/RT3, 110V//110V/RT3, 110V/RT3//110V, 415V/110V, 415V/110V/RT3, 415V/RT3//110V/RT3 |
| Frequency | : | 50Hz To 400Hz |
| No. Of Phase | : | Single Phase & Three Phase |
| Accuracy Class | Metering : 0.2, 0.5, 1 Protection : 3P, 6P& 5PR (Residual Protection) |
|
| Burden | : | Upto 100VA |
| System Earthing | : | Earthed/ Unearthed |
| Ambient Temperature | : | -50 C To +450 C |
| Applicable Standard | : | IS 3156 Part (1, 2 &3 ) , IEC 61869 Part (1 & 3) |
| Thermal Insulation Class | : | Class A, Class B & Class F |
| Type / Encapsulation | : | Resin Cast & Vacuum Pressure Impregnated (VPI) |
